Haas ST-35 CNC Turning Center, New in 2020
Have one to sell?
ConditionUsed
1 available
Haas ST-35 CNC Turning Center, New in 2020
General Specifications:
Bar Capacity: 4"
Chuck Size: 12"
Max Part Swing: 21"
Max Cutting Diameter: 15"
Max Turning Length: 32.5"
Max Bar Capacity: 4"
X Axis Travel: 9.4"
Z Axis Travel: 32.5"
Spindle Nose: A2-8
Spindle Motor: 40 HP
Spindle Speed: 3,200 RPM
Spindle Bore: 4.62"
Turret Stations: 12
Machine Dimensions: 121"L x 79"W x 83"H
Machine Weight: 14,300 lbs
Haas CNC Control
Programmable Tailstock
Tool Presetter
Chip Conveyor
Auto Door
300 PSI High Pressure Coolant
Auxiliary Coolant Filtration System
Auto Coolant Refill System
Enclosure Exhaust System
Coolant Tank Oil Skimmer
Chip Tray Filter Kit
High Intensity Lighting
Visual Part Programming
Media Display M-Code
Spindle Orientation
Rigid Tapping
Macros
Ethernet
USB Port
1GB Memory
WIFI Camera / Connectivity
Haasdrop
Haasconnect Remote Monitoring
