SMART MACHINE TOOL SM 1365 CAT40 12K CNC Vertical Machining Center, New in 2020
Have one to sell?
ConditionUsed
1 available
SMART MACHINE TOOL SM 1365 CAT40 12K CNC Vertical Machining Center, New in 2020.
Fanuc 0i-MF Control.
Renishaw OMI-2T.
TSC.
Chip Conveyor.
General Specifications:
X-Axis Travel: 51.1″
Y-Axis Travel: 25.6″
Z-Axis Travel: 24.2″
Table Size: 55.12″ x 31.50″
Spindle Speed: 12,000 RPM
Spindle Power: 25/20/15 HP
Spindle Taper: CAT40 Big Plus
Tool Changer: 36 ATC
Rapid Traverse: 1,181 IPM (590 IPM programmable)
Power: 220V, 3PH
Approximate Weight: 27,000 lbs
Approximate Dimensions: 134″ x 115″
Fanuc 0i-MF Control
Chip Conveyor
High Speed Machining with 200 Block Look Ahead
Coolant Through Spindle 290 PSI (1,000 PSI prep)
Renishaw OMI-2T Preparation Kit and GUI Software
SMART MACHINE TOOL SM 1365 CAT40 12K CNC Vertical Machining Center, New in 2020.
Fanuc 0i-MF Control.
Renishaw OMI-2T.
TSC.
Chip Conveyor.
Imperial
| X-Axis | 51.18" |
| Y-Axis | 25.59" |
| Z-Axis | 24.02" |
| Power | 25 hp |
| RPM | 12,000 RPM |
| # ATC | 36 |
| Taper | CAT40 (BIG PLUS) |
| Table-W | 31.5" |
| Table-L | 55.12" |
| Control | CNC (Fanuc 0IMF) |
| Dimensions | 134" x 115" |
| Weight | 27,000 lbs |
General Specifications:
X-Axis Travel: 51.1″
Y-Axis Travel: 25.6″
Z-Axis Travel: 24.2″
Table Size: 55.12″ x 31.50″
Spindle Speed: 12,000 RPM
Spindle Power: 25/20/15 HP
Spindle Taper: CAT40 Big Plus
Tool Changer: 36 ATC
Rapid Traverse: 1,181 IPM (590 IPM programmable)
Power: 220V, 3PH
Approximate Weight: 27,000 lbs
Approximate Dimensions: 134″ x 115″
Fanuc 0i-MF Control
Chip Conveyor
High Speed Machining with 200 Block Look Ahead
Coolant Through Spindle 290 PSI (1,000 PSI prep)
Renishaw OMI-2T Preparation Kit and GUI Software
