HAAS VF-6SS CNC Vertical Machining Center, New in 2017
Have one to sell?
ConditionUsed
1 available
HAAS VF-6SS CNC Vertical Machining Center, New in 2017.
12,000 RPM.
WIPS.
HSM Mill.
Only 343 cutting hours!
General Specifications:
X-axis 64″
Y-axis 32″
Z-axis 30″
Rapid traverse rates 1200 IPM
Cutting feed rates 833 IPM
Length 64″
Width 28″
Number of std t-slots 5
T-slot width 5/8″
Max weight on table 2000 Lbs
Taper size CAT-40
Speed range 12,000 RPM
Spindle power 30 HP
Vector drive max torque 90ft-lb @ 2000 RPM
Capacity 24 Station Side Mounted
Tool weight 12 Lbs
Max tool diameter (full) 2.5″
Max tool length 16″
Tool changing time 3.2 Seconds
Air required 100 psi, 4 scfm
Power 220v / 66FLA / 3-Phase
Overall dimensions 195″ x 102″ x 130″ High
Weight 22,300 lbs Approx.
HAAS CNC Control.
12,000RPM
24 Station High Speed Tool Changer.
WIPS.
Probe Riser Block.
Programmable Coolant Nozzle.
Rigid Tapping.
Spindle Orientation.
VPS Editing.
32GB Max Memory.
Chip Auger.
