ble working surface: 15” x 68”
Longitudinal travel: 36”
Cross travel: 12”
Knee travel: 18”
Spindle speeds: (24) 25 to 2000 RPM
Taper in spindle: #50
Feeds: (32) 3/8 to 90 IPM
Main motor: 15HP 220/440V
Approx. weight: 10,000#
Approx. dimensions: 6-1/2’L x 6-1/2’W x 6-1/2’H
Complete with:
• 3 way power rapid traverse & feeds
• Arbor support
• Coolant pump
• Universal table
