Okuma Impact LU45 CNC Turning Center

Swing Over Bed: 33.07″
Swing Over Saddle: 21.85″
Distance Between Centers: 78.74″
Maximum Turning Diameter: 25.98″
Maximum Work Length: 78.74″
X-axis Travels: Upper Turret 17.32″/ Lower Turret: 12″
Y-axis Travels: Upper Turret 82.28″/ Lower Turret 79.72″
Speed Range: 12-2800 Rpm
Number Of Speed Ranges: 4 Ranges
Spindle Nose: Jis A2-11
Spindle Bore Diameter: 4.33″
Diameter At Front Bearing: 5.91″
Turret Type: Upper Turret V12 / Lower Turret V10
Number Of Tool Stations: Upper Turret 12 / Lower Turret 10
Tool Shank Height: 1.26″ X 1.26″
Boring Bar Shank Diameter: 2.48″
Turret Indexing Time: 0.7 Seconds (lift Up)
Rapid Traverse Rate (x,z): 591 Ipm / 787 Ipm
Cutting Feed Rate: 0.0001-40.0 Ipr
Tailstock Quill Diameter: 5.12″
Tailstock Quill Bore Taper: Mt 5 (built-in)
Tailstock Quill Travel: 6.69″
Spindle Motor: 60/50 Hp
Coolant Pump Motor: 0.7 Hp
Power Kva: 54.3
Machine Height: 119.69″
Machine Floor Space: 238.58″ X 111.49″
Machine Weight: 45,540 Lbs
