Hyundai Wia VX-500 CNC Vertical Machining Center
Have one to sell?
ConditionUsed
1 available
Hyundai Wia VX-500 CNC Vertical Machining Center
New 2009
X Axis Travel: 41.7"
Y Axis Travel: 20.1"
Z Axis Travel: 25"
Rapid Rate X Axis: 1,417
IPM Rapid Rate Y Axis: 1,417 IPM
Rapid Rate Z Axis: 1,181 IPM
Table Size: 47.2" x 19.7"
Max Table Load: 1,763 LBS
Spindle Motor: 25 HP
Spindle Speed: 10,000 RPM
Spindle Taper: 40 CT
Distance from table to spindle nose: 5.9" to 30.9"
Distance from column to spindle center: 24.2"
Tool Changer: 24 ATC
Machine Dimensions: 122" x 117" x 114"
Machine Weight: 16,534 LBS
Fanuc OiMC Control
Chip Conveyor
Through Spindle Coolant
24 ATC
10,000 RPM
