Haas VF-2SS Vertical Machining Center, New in 2018
Have one to sell?
ConditionUsed
1 available
Haas VF-2SS Vertical Machining Center, New in 2018
General Specifications:
X-Axis Travel: 30″
Y-Axis Travel: 16″
Z-Axis Travel: 20″
Table Size: 36″ x 14″
Max Table Load: 1500 lbs
Spindle Speed: 12,000 RPM
Spindle Motor: 30 HP
Spindle Taper: CAT40
Rapids (X, Y, Z): 1400 IPM
Max Cutting Feed Rate: 833 IPM
Tool Capacity: 30+1
Machine Weight: 7,800 lbs
Machine Dimensions: 98" X 92" X 94"
Haas CNC Control
Chip Auger
Coolant Pan
Haas VF-2SS Vertical Machining Center, New in 2018
Imperial
| X-Axis | 30" |
| Y-Axis | 16" |
| Z-Axis | 20" |
| Power | 30 hp |
| RPM | 12,000 RPM |
| # ATC | 30 |
| Taper | CT40 |
| Table-W | 14" |
| Table-L | 36" |
| Control | CNC (Haas) |
| Dimensions | 98" X 92" X 94" |
| Weight | 7,800 lbs |
General Specifications:
X-Axis Travel: 30″
Y-Axis Travel: 16″
Z-Axis Travel: 20″
Table Size: 36″ x 14″
Max Table Load: 1500 lbs
Spindle Speed: 12,000 RPM
Spindle Motor: 30 HP
Spindle Taper: CAT40
Rapids (X, Y, Z): 1400 IPM
Max Cutting Feed Rate: 833 IPM
Tool Capacity: 30+1
Machine Weight: 7,800 lbs
Machine Dimensions: 98" X 92" X 94"
Haas CNC Control
Chip Auger
Coolant Pan
