DOALL 400S Horizontal Band Saw, New in 2026
Have one to sell?
ConditionNew
$23,522.00 USD
New
DOALL 400S Horizontal Band Saw, New in 2026.
Saw Blade:
Width x Length 1" x 158"
Band Drive:
Motor HP 2Hp VFD
Band Speed 50-400fpm
Band Tension Manual
Hydraulic System:
Motor Hp N/A
Reservoir Size N/A
Coolant System: Flood Yes/ Mist Lubricator OPT
Motor Hp 1/15 Hp
Reservoir Size 6 Gallon
Indexer:
Length per Stroke N/A
Maximum Strokes Length N/A
Remnant Length N/A
Floor Space Dimensions:
W x L x H 87" x 42' x 55"
Material Pass Height 29"
Machine Weight 1,200lbs
Electrical:
Voltage Requirement 208V, 230V or 460V-60Hz-3ph, Wye configuration
(Must Specify at Order Placement)
Total Amp Draw (FLA)7.2(208) 6.9(230) 3.5(460) Amps
-Swivel head to 45 degrees.
-Fine adjustment head feed control.
-Fixed control console.
-Rapid head down approach.
-Spring loaded, zero clearance, coolant through, carbide faced saw guide inserts.
-Quick action rack and pawl vise system w/Acme Thread.
-Gear driven band cleaning brushes.
-Variable Frequency Drive.
-Heavy duty counter balance spring.
-Flange backing band wheels.
-Manual band tension.
-Recirculating coolant system.
-Discharge Tray.
Replaceable steel wear plates on bed.
-Saw blade guards.
Band door interlocks.
-Operation and parts manuals on USB stick.
- Recommended band speed chart.
- One (1) complimentary DoALL Bi Metal saw blade.
- Complimentary DoALL Cutting Fluids package.
DOALL 400S Horizontal Band Saw, New in 2026.
Imperial
| Rect-Cap (H) | 10" |
| Rect-Cap (W) | 16" |
| Rounds-Cap | 10.75" |
| Power | 2 hp |
| Type (Auto, Manual, Semi) | Manual |
| Blade Width | 1" |
| Blade Thickness | 0.035" |
| Blade Length | 158" |
| Dimensions | 87"W x 42"L x 55"H |
| Weight | 1,200 lbs |
Saw Blade:
Width x Length 1" x 158"
Band Drive:
Motor HP 2Hp VFD
Band Speed 50-400fpm
Band Tension Manual
Hydraulic System:
Motor Hp N/A
Reservoir Size N/A
Coolant System: Flood Yes/ Mist Lubricator OPT
Motor Hp 1/15 Hp
Reservoir Size 6 Gallon
Indexer:
Length per Stroke N/A
Maximum Strokes Length N/A
Remnant Length N/A
Floor Space Dimensions:
W x L x H 87" x 42' x 55"
Material Pass Height 29"
Machine Weight 1,200lbs
Electrical:
Voltage Requirement 208V, 230V or 460V-60Hz-3ph, Wye configuration
(Must Specify at Order Placement)
Total Amp Draw (FLA)7.2(208) 6.9(230) 3.5(460) Amps
-Swivel head to 45 degrees.
-Fine adjustment head feed control.
-Fixed control console.
-Rapid head down approach.
-Spring loaded, zero clearance, coolant through, carbide faced saw guide inserts.
-Quick action rack and pawl vise system w/Acme Thread.
-Gear driven band cleaning brushes.
-Variable Frequency Drive.
-Heavy duty counter balance spring.
-Flange backing band wheels.
-Manual band tension.
-Recirculating coolant system.
-Discharge Tray.
Replaceable steel wear plates on bed.
-Saw blade guards.
Band door interlocks.
-Operation and parts manuals on USB stick.
- Recommended band speed chart.
- One (1) complimentary DoALL Bi Metal saw blade.
- Complimentary DoALL Cutting Fluids package.
